Quick Details

  • Type: Gps Tracker
  • Use: Automotive
  • Screen Size: None
  • Function: Other
  • Place of Origin: Guangdong, China (Mainland)
  • Brand Name: SEEWORLD
  • Model Number: S208
  • Warranty: 12 Months
  • Item Name: Car GPS Tracker
  • GSM module: GSM 850/900/1800/1900Mhz
  • GPS module: GPS S IRF-Star III CMOS chip group
  • GPS sensitivity: -159dBm
  • GPS frequency: L1, 1575.42 MHz
  • Position accuracy: 10 meter, 2D RMS
  • Speed accuracy: 0.1 meter/second
  • Time accuracy: GPS synchronization
  • Working voltage: 8VDC~36VDC
  • Working current: 50mA~160mA

Packaging & Delivery

Packaging Details: Color box or neutral English packing
Delivery Detail: Shipment within 3 days after payment

Car gps tracker with sms remote power cut-off vibration alarm gps tracking device SEEWORLD S208

Products Features

________________________________________________________________________________________________________



(1) Accurate GPS positioning,dynamic positioning deviation
(2) GSM voice and SMS, support UDP/TCP
(3) GPS data uploading at intervals and location
(4) Two way voice communication
(5) Call Barring of group numbers
(6) SMS communication via Mobile and PC software
(7) The mute function; Authorized tapping
(8) Protection from high or low level voltage
(9) 5 levels of signal detection
(10) Data resend from signal dead zone
(11) Remotely locking vehicle;remote update
(12) SOS alarm;Power-off alarm,over speed alarm
(13) High-voltage under-voltage alarm
(14) Parking alarm;Geo-fence alarm;fatigue driving alarm
(15) Illegal door-open, illegal engine-start alarm
(16) Fuel consumption detection;fuel changing alarm
(17) Mileage statistics;Temperature detection alarm
(18) Support LED,Scheduling screen,handles,camera,etc.



Specifications

________________________________________________________________________________________________________

Working voltage8VDC~36VDC
Working current50mA~160mA
GSM moduleInside contain frequency GSM 900/1800
Iside contain frequency GSM 850/900/1800/1900Mhz (can tailor)
Communication protocolUDP/TCP(can customize)
GPS moduleGPS S IRF-Star III CMOS chip group
GPS sensitivity-159dBm
GPS frequencyL1, 1575.42 MHz
C/A coding1.023 MHz chip rate
Channels20 channels for tracking
Position accuracy10 meter, 2D RMS
Speed accuracy0.1 meter/second
Time accuracyGPS synchronization
Default dataWGS-84
RecoverAverage 0.1 second
Hot startAverage 1 second
Warm startAverage 38 second
Cold startAverage 42 second
Height limit18,000 meter (60,000 feet) max
Speed limit515 kilometer/second (1000 knots)max
Acceleration limitLess than 4g
Expansion peripheralPeripherals can be accessed by an extension
(such as: Handle / scheduling screen / camera etc.)
Work temperature-20°~ 70° C
Storage temperature-30°~ 85° C
Humidity5% ~ 95% non-condensing
Terminal size97 mm × 64mm × 24mm
Inside batteryContinuing working not less than 4 hours
LED lightRed: power-on state;Yellow:communication module state;
Green:GPS module working state



Accersories

________________________________________________________________________________________________________

GPS Antenna
GSM Antenna
Relay
I/O Cable
USB Data Cable
User manual

Package&Shipment

________________________________________________________________________________________________________

Shiping out within 10 days

Color box or neutral English packing















Applications

________________________________________________________________________________________________________





Platform

________________________________________________________________________________________________________





Company Informations

________________________________________________________________________________________________________

Customers

________________________________________________________________________________________________________





Why buy from us

________________________________________________________________________________________________________



High-tech technique

We supply precision molds with self-developed ability

A professional design team

OEM/ODM is Welcome

High quality control standard

Measureable standards in line and final inspections to meet the evolving

 requirements of our market, fully complying with our customers' requirement.

A professional GPS manufacturer

with 8 years experiences

Exporting all kinds of GPS tracking system,gps navigation,gps data logger,

car dvr ,gps dvr etc. to Europe, America, East Asia, the Mid-East, Japan, and Korea

Our mission

Customer first; Sincere cooperation; Mutually beneficial; Joint development
